Sysolution Single Window Processor 2 In 1 SY20 2 Ethernet Outputs,1.3 million pixel capacity

Name: Sysolution Single Window Processor 2 In 1 SY20 2 Ethernet Outputs13 million pixel capacity
Brand: Sysolution
Price: 1 USD

Price : Negotiation

Supply Ability : 30 units per week

Input Voltage : AC-100-240V-50/60HZ

Szie : 430*251*44mm

HDMI Input : 1 port

USB playback : 1 USB input

Net Weight : 3.85 kg

Operating Temperature : -20℃ - +70℃

Certification : FCC，CE certification

Load Capacity of Single Network Port : 1,300,000 pixels

Brand Name : Sysolution

Model Number : SY20

Place of Origin : China

MOQ : 1

Payment Terms : T/T,PayPal

Delivery Time : 2-3 working days

Packaging Details : One piece of equipment per box. Accessories include: 1 USB cable, 1 DVI cable, 1 VGA cable, and 1 HDMI cable

Contact Now

Sysolution 2 In 1 Video Processor SY20

Features:

HDMI video input (channel 1)
USB port 1 supports USB flash drive playback with plug-and-play functionality
2 Gigabit network ports with output, supporting vertical and horizontal splicing
Supports network port loop backup and dual controller backup
Supports upper computer software to monitor and send card operation parameters and status
Supports configuration parameter readback
Supports custom input of EDID
Supports gigabit network bit error rate detection
Supports audio input and output
Support image scaling

Application Scenarios:

It is suitable for many application scenarios such as small and medium-sized LED displays in shopping malls, hotels, exhibitions, TV studios, etc.

Product Parameters:

Standard Version
Load capacity	Single network port	650,000 pixels
	Full card	1.3 million pixels
Output resolution	1.The pixel count is limited to 1.3 million. 2.Maximum width: 3840 Maximum height: 1920 3.When the horizontal count exceeds 1920, the vertical count must be within 1080. 4.When the vertical points exceed 1080, keep the horizontal points within 1080.
Input resolution	Supports video input with a maximum resolution of 1920×1080@60Hz, backward compatible

Working Parameters:

Electrical parameters	Input Voltage	AC-100-240V-50/60HZ
	Rated Power	11W
Operating Environment	Operating Temperature	-20℃~+70℃
	Operating Humidity	10%RH-90%RHNo Freezing
Overall Dimensions	Body size:430x251x44mm(Length x width x height)
Net Weight	3.85Kg
Packaging information	One piece of equipment per box. Accessories include: 1 USB cable, 1 DVI cable, 1 VGA cable, and 1 HDMI cable

Electrical parameters:

Electrical parameters	input voltage	DC 5V
Electrical parameters	power rating	3W
Work environment	working temperature	-20℃ - 60℃
Work environment	working humidity	10% RH-80%RH non-coagulated
Outline dimension	Case dimensions: 480mm x 101mm x 43mm (including front mounting brackets) Case dimensions: 250mm x 101mm x 43mm (excluding front mounting ears)
Net weight	0.65Kg
Packaging Information	carton size	312 X 206 X 136mm
	fittings of a machine	1 USB cable, 1 HDMI cable, 1 certificate of conformity, 1 power cord, 2 front mounting ears
	gross weight of a single unit	1.22 kg Note: Includes all wires and packaging
	packaging method	7 units per box

Cautions:

1. High voltage danger: The working voltage of this product is AC -100V～240V.

2. It is forbidden to immerse conductive objects such as liquids and metal fragments into the equipment to avoid safety accidents.

3. Please use the equipment in a dry and clean environment.
